Display
11.6” FHD (1920 x1080)
Optional 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen
Optional with digitizer
User selectable touch mode for Finger/Water, Glove, or Stylus programmable function

Operating System
Windows® 11 Pro 64-bit

Processors
Intel® Core™ i7-1250U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.7 GHz, 2P+8E cores)
Intel® Core™ i5-1230U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.4 GHz, 2P+8E cores)

Memory
Onboard 8GB up to 32GB (LPDDR4x)

Storage
256GB NVMe PCIe SSD
Optional 512GB/1TB/2TB PCIe SSD
Optional OPAL 2.0 SSD

Graphics
Intel® Iris® Xe Graphics

Camera
Integrated 2.0MP front-facing camera
Optional 11.0MP auto-focus rear camera with flash
Optional 5.0MP IR camera for Windows Hello

Audio
Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 2

I/O Ports
Thunderbolt 4 x 1
USB 3.2 Gen1 (type A) x 1
Audio in/out (combo jack) x 1
microSD card (microSDHC, microSDXC) x 1
10/100/1000 Ethernet (RJ45) x 1
Docking connector (20-pin Pogo) x 1
Nano SIM card x 1
DC-In jack x 1
Optional smart card reader x 1 or x 2
Optional USB 3.2 Gen2 (type C) x 1
Optional 2nd USB 3.2 Gen1 (type A) x 1
Optional USB 2.0 (type A) x 1
Optional serial port (RS232, 422 and 485 : D-sub, 9-pin) x 1
Optional 1D/2D barcode reader x 1
Optional RF antenna pass-through for GPS, WWAN, and WLAN

Expansion Slots
Optional ExpressCard 54 or LF/HF-RFID (NFC) or 2nd smart card reader

Keyboard & Input
5 buttons (2 user-definable keys)

Communications
Integrated 10/100/1000 Ethernet
Intel® Wi-Fi 6E AX211 (802.11ax)
Bluetooth® V5.3
Optional dedicated GPS module (UBLOX-NEO-M9N)
Optional 4G LTE multi-carrier mobile broadband
Optional 5G (project based)
Optional RF antenna pass-through for GPS, WWAN, and WLAN

Security
Intel® vPro™ Technology
Secured-core PC
TPM 2.0
NIST BIOS compliant
Easy removable SSD
Stealth mode
Kensington lock
Optional smart card reader x 1 or x 2
Optional Windows Hello
Optional night vision mode
Optional fingerprint scanner
Optional LF/HF-RFID (NFC) reader

Power
AC adapter: 100-240V, 50Hz-60Hz, 65W
Main battery: Li-Ion, 7.6V, 4800mAh, 10 hours
Optional hi-cap battery Li-Ion 7.6V, 9600mAh, 20 hours
Optional bridge battery: 5 minutes swap time

Dimension & Weight
317 mm (L) x 215 mm (W) x 23.8 mm (H)
1.39 kg

Warranty
3-year limited warranty standard
