Tech Specs

Display
8.0” LCD (1280 x 800)
800 nits DynaVue® sunlight readable display with capacitive multi-touch screen
Optional with digitizer
User selectable touch mode for Finger/Water, Glove or Stylus programmable function

Operating System
Windows® 11 Pro 64-bit

Processors
Intel® Core™ i7-1250U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.7 GHz, 2P+8E cores)
Intel® Core™ i5-1230U (12th Gen) Processor with vPro™ (12MB Cache, up to 4.4 GHz, 2P+8E cores)
Intel® Pentium® Gold Processor 8500 (8MB Cache, up to 4.4 GHz, 1P+4E cores)

Memory
Onboard 8GB up to 16GB (LPDDR4x)

Storage
128GB NVMe PCIe SSD
Optional 256GB/512GB/1TB PCIe SSD

Graphics
Intel® UHD Graphics

Camera
Integrated 2.0 MP front-facing camera
Optional 11.0 MP auto-focus rear camera with flash

Audio
Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 1

I/O Ports
Thunderbolt 4 x 1
USB 3.2 Gen2 (type C) x 1 (support DP)
Audio in/out (combo jack) x 1
microSD card (microSDXC) x 1
Docking connector (20-pin Pogo) x 1
Nano SIM card x 1
DC-In jack x 1
Optional USB 3.2 Gen1 (type A) x 1
Optional 10/100/1000 Ethernet (RJ45) x 1
Optional serial port (RS232) x 1
Optional 1D/2D barcode reader x 1
Optional RF antenna pass-through for GPS, WWAN and WLAN

Keyboard & Input
4 buttons (1 user-definable key)

Expansion Slot
Optional magnetic stripe reader
Optional smart card reader with LF/HF-RFID (NFC) or UHF-RFID (NFC) or RS232/RJ45/USB 3.2 Gen1 (type A)

Wireless & Communications
Intel® Wi-Fi 6E AX211 (802.11 ax)
Bluetooth® V5.3
Optional dedicated GPS module
Optional GPS and 4G LTE multi-carrier mobile broadband
Optional RF antenna pass-through for GPS, WWAN and WLAN

Security
Intel® vPro™ Technology (per CPU options)
TPM 2.0
NIST BIOS compliant
Stealth mode
Night vision mode
Optional smart card reader
Optional LF/HF-RFID (NFC) reader
Optional UHF-RFID (NFC) reader

Power
AC adapter : 100-240V, 50Hz-60Hz, 65W
Main battery Li-Ion, 7.6V, 3600mAh, 8.5 hours
Optional long life battery Li-Ion 7.6V, 7200mAh, 17 hours
Optional swappable battery: 5 minutes swap time

Dimension & Weight
227 mm (L) x 150 mm (W) x 20.5 mm (H)
0.86 kg

Warranty
3-year limited warranty standard
